Before we begin, let's discuss why you want to secure your applications with the IDlayr SubscriberCheck API.

The IDlayr SubscriberCheck API

The IDlayr SubscriberCheck API confirms the ownership of a mobile phone number by verifying the possession of an active SIM card with the same number. It also exposes a flag that indicates if the SIM card associated with the mobile phone number has changed within the last seven days. This check provides the security required for passwordless login with the addition of attempted fraud detection.

All your user needs to do is provide a phone number, and the API will verify that number is associated with their device. It can be used as a primary user verification mechanism or as an added layer of security against SIM swapping/theft within existing 2FA workflows. In this tutorial, we'll use SubscriberCheck as a standalone authentication mechanism.

The SubscriberCheck workflow is as follows:

1. Get the user's phone number on the mobile device
2. Send the phone number to the application server
3. Create a SubscriberCheck using the SubscriberCheck API
4. Return the SubscriberCheck URL to the mobile device
5. Request the SubscriberCheck URL on the mobile device over mobile data
6. Mobile device requests the SubscriberCheck result via the application server
7. Application server completes the phone check a PATCH request to IDlayr's API
8. Application server returns the SubscriberCheck result, including SIM changed status, to the mobile device

In this tutorial, we'll use a ready-made server and focus on the steps involving the React Native application.

Before you begin

Before you begin, there are a few requirements that have to be met:

• An Android or Apple device with a SIM card and mobile data connection
• For iOS: XCode >12
• For Android:
  • JDK 14 (Java version 14.02 / Gradle v6.3).
  • Android Studio or Android SDK manager via Android developer downloads. VS Code would work as you aren't using a virtual device.
  • Set up the React Native Environment
• For metro bundler, Node.js version > 10

Getting Started

npm install -g @tru_id/cli

Success. Tokens were written to /Users/user/.config/@tru_id/cli/config.json. You can now close the browser

tru projects:create rn-auth --project-dir .

git clone [email protected]:tru-ID/dev-server.git

cp .env.example .env

NGROK_ENABLED=true
#NGROK_SUBDOMAIN=a-subdomain # Uncommenting this is optional. It is only available if you have a paid ngrok account.

NGROK_AUTHTOKEN=<YOUR_NGROK_AUTHTOKEN> # This is found in the ngrok dashboard: https://dashboard.ngrok.com/get-started/your-authtoken
NGROK_REGION=eu # This is where your ngrok URL will be hosted. If you're using IDlayr's `eu` data residency; leave it as is. Otherwise, you could specify `in` or `us`.

npm install # Installs all third-party dependencies in package.json
npm run dev # Starts the server

To follow along with this tutorial, head over to the Passwordless Authentication with React Native repo and clone the starter-files branch via:

git clone -b starter-files https://github.com/tru-ID/passwordless-auth-react-native.git

To install dependencies, open a new terminal, cd passwordless-auth-react-native, and run:

npm install

Once you've finished that step, start the Metro server:

npm start

Then, to run on Android, ensure your Android device is connected via USB and run:

npm run android

To run on your iOS device, ensure it's connected via USB, open ios/simcardauthrn.xcworkspace in XCode, and run the project.

Your app should look like this:

Get the User's Phone Number on the Mobile Device

Let's start by adding the UI and state management required for the user to input (TextInput) and submit their phone number (TouchableOpacity). We'll also add a UI and state to check if any work is in progress via a loading variable or an error has occurred via error.

const App = () => {
  const [phoneNumber, setPhoneNumber] = React.useState('')
  const [loading, setLoading] = React.useState(false)
  const [error, setError] = React.useState(null)

  React.useEffect(() => {
    if (error) {
      showMessage({
        message: error,
        type: 'danger',
        style: styles.toastContainer,
      })
    }
  }, [error])

  // we'll handle SubscriberCheck in the function below
  const onPressHandler = () => {}

  return (
    <>
      <StatusBar barStyle="light-content" />
      <SafeAreaView style={styles.container}>
        <Image style={styles.logo} source={require('./images/tru-logo.png')} />
        <Text style={styles.heading}>Enter your phone number</Text>
        <Text style={styles.paragraph}>and we'll handle the rest</Text>
        <View style={styles.center}>
          <TextInput
            style={styles.textInput}
            keyboardType="phone-pad"
            placeholder="ex. (415) 555-0100"
            placeholderTextColor="#d3d3d3"
            onChangeText={(text) => setPhoneNumber(text)}
            value={phoneNumber}
          />

          {loading ? (
            <ActivityIndicator
              style={styles.spinner}
              size="large"
              color="#00ff00"
            />
          ) : (
            <TouchableOpacity onPress={onPressHandler} style={styles.button}>
              <Text style={styles.buttonText}>Authenticate</Text>
            </TouchableOpacity>
          )}
        </View>
      </SafeAreaView>
      <FlashMessage />
    </>
  )
}

Your app should now look like this:

The user will begin the SubscriberCheck Authentication by clicking the TouchableOpacity (button). So, we need to set the loading state and create the payload to submit to the server. We do this within the onPressHandler function:

const onPressHandler = async () => {
  setLoading(true)
  const body = {
    phone_number: phoneNumber,
  }
  console.log(body)
}

Set the loading state to true to give the user a visual cue that works (an HTTP network request) is in progress via our loading indicator. Next, we construct the body object setting the phone_number field to the phoneNumber.

Create a SubscriberCheck using the SubscriberCheck API

With our body request payload ready, we're ready to make requests to our server. First, let's import and setup Axios in our development server is:

import FlashMessage, { showMessage } from 'react-native-flash-message'

import axios from 'axios'
axios.defaults.baseURL = 'https://{subdomain}.{region}.ngrok.io'

Remember to replace https://{subdomain}.{region}.ngrok.io with your development server URL.

Then update the onPressHandler to make a request to create a SubscriberCheck:

const onPressHandler = async () => {
  setLoading(true)
  const body = {
    phone_number: phoneNumber,
  }
  console.log(body)

  try {
    const response = await axios.post('/v0.2/subscriber-check', body)
    console.log(response.data)
  } catch (e) {
    setLoading(false)
    setError(e.message)
  }
}

Here, we make a network request to our app server's SubscriberCheck endpoint to get back the SubscriberCheck URL (check_url) and the check_id, which we'll use in a future step.

Request the SubscriberCheck URL on the Mobile Device over Mobile Data

The next step is requesting the SubscriberCheck URL on the mobile device over mobile data. For this, we'll use the tru.ID (IDlayr) React Native SDK.

The first step is to install it via:

npm install @tru_id/tru-sdk-react-native

Note: After installing the SDK, you should restart your Metro server, re-run npm run android, and clean the XCode build to ensure the changes are picked up.

Then add the import to the top of App.js:

import TruSdkReactNative from '@tru_id/tru-sdk-react-native'

The tru.ID (IDlayr) React Native SDK openWithDataCellular(checkUrl) function forces the request to the SubscriberCheck URL (check_url) to go over the mobile data connection.

Add the openWithDataCellular call to the onPressHandler:

const onPressHandler = async () => {
  setLoading(true)
  const body = {
    phone_number: phoneNumber,
  }
  console.log(body)

  try {
    const response = await axios.post('/v0.2/subscriber-check', body)
    console.log(response.data)

    const checkResponse = await TruSdkReactNative.openWithDataCellular(
      response.data.check_url
    );

    console.log('check_url request compeleted')
  } catch (e) {
    setLoading(false)
    setError(e.message)
  }
}

Complete the SubscriberCheck and get the result via the Application Server

With the check_url request complete, you now need to take the check_url and code received in the final redirect of the check_url, and pass that to the application server. The application server will then make a PATCH request to IDlayr's API in order to complete the SubscriberCheck, and return the response back to the mobile application.

Add a new stateful value called data:

const App = () => {
  const [phoneNumber, setPhoneNumber] = React.useState('')
  const [loading, setLoading] = React.useState(false)
  const [error, setError] = React.useState(null)
  const [data, setData] = React.useState(null)

  React.useEffect(() => {
    ...

Make a request to the /v0.2/subscriber-check/exchange-code endpoint to get the result, save it to state with setData, and set loading to false above the line } catch (e) {:

if ('error' in checkResponse) {
  console.log(`Error in openWithDataCellular: ${checkResponse.error_description}`)
  setLoading(false)
  showMessage({
    message: 'Verification failed',
    type: 'danger',
    style: styles.toastContainer,
  })
} else if ('http_status' in checkResponse) {
  const httpStatus = checkResponse.http_status

  if (httpStatus === 200 && checkResponse.response_body !== undefined) {
    console.log(`Requesting PhoneCheck URL`)

    if ('error' in checkResponse.response_body) {
      const body = checkResponse.response_body
      console.log(`Error: ${body.error_description}`)
      showMessage({
        message: `Verification failed: ${body.error_description}`,
        type: 'danger',
        style: styles.toastContainer,
      })
    } else {
      const body = checkResponse.response_body

      try {
        const checkStatusRes = await axios.post('/v0.2/subscriber-check/exchange-code', { check_id: body.check_id, code: body.code })

        console.log('[CHECK RESULT]:', checkStatusRes.data)

        setData(checkStatusRes.data)
        setLoading(false)
      } catch (error) {
        showMessage({
          message: `Error retrieving check result: ${error.message}`,
          type: 'danger',
          style: styles.toastContainer,
        })

        return;
      }
    }
  } else {
    const body = resp.response_body;
    showMessage({
      message: `Error: ${body.detail}`,
      type: 'danger',
      style: styles.toastContainer,
    })
  }
}

With that in place, your app will look as follows when creating the SubscriberCheck, requesting the check_url using the tru.ID (IDlayr) SDK, and then retrieving the SubscriberCheck result:

Updating the UI with the result

The last thing we need to do is inform users whether or not there is a SubscriberCheck match (i.e., the phone number is verified) and if the SIM has changed recently. For this, we'll use toast notifications.

In your App(), at the top add the following useEffect:.

//check if there is a match, i.e., the phone number has been verified and no_sim_change and render toast UI
React.useEffect(() => {
  if (data) {
    data.match && data.no_sim_change
      ? showMessage({
          message: 'Phone Verified',
          type: 'success',
          style: styles.toastContainer,
        })
      : showMessage({
          message: 'Verification failed',
          type: 'danger',
          style: styles.toastContainer,
        })
  }
}, [data])

In this React.useEffect function we add data as a dependency, so whenever data changes the effect re-runs. Inside the effect, we check if we have data and subsequently check if we have a match and if the SIM has not changed. If both are confirmed, we render a toast UI with a Phone Verified message (this can be anything you want). Otherwise, we render a toast UI with a Verification failed. Please Try Again Later message.

Your UI, if the SubscriberCheck is successful, should look like this:

Wrapping Up

There you have it: you’ve successfully integrated IDlayr SubscriberCheck with your React Native application to build a passwordless signup or login flow. The application verifies a phone number and determines if the SIM card for the device has changed recently.

Resources

• SubscriberCheck Integration Guide
• React Native SDK on GitHub
• Node.js Development Server on GitHub

Get in touch

If you have any questions, contact [email protected].
